SCULPTURE™
GLAZED PORCELAIN/GLAZED CERAMIC WALL TILE
Description
Sculpture™ is inspired by the artistic beauty of white Italian marble. Sculpture™ is available in a matte finish, perfect for floors, along with a gloss finish to coordinate with walls.
2 Colors | 2 Patterns | 2 Sizes
Technical Specifications
| Nominal Size (in.) | 12 x 24 Floor | 13 x 36 Wall |
| Edge Detail | Pressed | Pressed |
| Finish | Satin | Glossy |
| Faces | 26 | 26 |
| Thickness (in.)* | 3/8 | 3/8 |
| Lbs/PC | 8.27 | 11.9 |
| Grout Joint Recommendation (in.) | 3/16 | 1/16 |
* Tile thickness could vary based on size. Larger format tiles will have a higher thickness.
Testing
| Method | Results |
| Abrasion Resistance C1027* |
Floor: IV |
| Breaking Strength C648 | Floor: >500 lbf Wall: >300 lbf |
| Chemical Resistance C650 | Floor: Resistant Wall: Non-Resistant |
| Water Absorption C373 |
Floor: ≤0.50 Wall: >7.00 |
|
DCOF AcuTest WET |
Floor: >.60 Wall: N/A |
| Freeze-Thaw Cycling C1026 |
Floor: Resistant Wall: Non-Resistant |
| Scratch Hardness MOHS |
Floor: 6 Wall: 5 |
| Shade Variation |
Floor: V2 Wall: V1 |
| Pre-Consumer Recycled Content | 0% |
| Post-Consumer Recycled Content | 0% |
| VOC | None |
Download and View Care and Maintenance
* The beauty of high gloss or polished products may be susceptible to scratching that is more visible on the surface of the tile.
Sizes and Trim
Usage
| USAGE TYPES: | YES/NO |
| COMMERCIAL FLOOR* | Flat Only |
| RESIDENTIAL FLOOR |
|
| RESIDENTIAL AND COMMERCIAL WALL | Yes |
| SHOWER WALL | Yes |
| SHOWER FLOOR |
|
| STEAM SHOWER |
|
| KITCHEN COUNTER |
|
| STOVE AREA |
|
| FIREPLACE FACADE |
|
| COVERED EXTERIOR WALL FREEZING CLIMATES |
|
| COVERED EXTERIOR WALL NON-FREEZING CLIMATES |
|
| UNCOVERED EXTERIOR WALL FREEZING CLIMATES |
|
| UNCOVERED EXTERIOR WALL NON-FREEZING CLIMATES |
|
| COVERED EXTERIOR FLOOR FREEZING CLIMATES |
|
| COVERED EXTERIOR FLOOR NON-FREEZING CLIMATES |
|
| UNCOVERED EXTERIOR FLOOR FREEZING CLIMATES |
|
| UNCOVERED EXTERIOR FLOOR NON-FREEZING CLIMATES |
|
| POOL DECK |
|
| POOL WATERLINE |
|
| INSIDE POOL |
|
| SPA / HOT TUB |
|
| UV/ SUN EXPOSURE SENSITIVE |
|
* Emser recommends a .50 or greater DCOF for Commercial Dining Floors.
The usage chart is provided as a general guide only. Actual job site conditions may change a product’s suitability for a specific application. If special conditions apply, please contact an Emser representative for clarification of use prior to purchasing.
