NETWORK™

GLAZED PORCELAIN

Network™ is a recreation of concrete with an industrial, avant-garde look. Offered in large format sizes and stunning hues, Network™ is sure to create a bold statement.

3 Colors | 3 Sizes

Technical Specifications

Nominal Size (in.) 12 x 23 23 x 47 31 x 31
Edge Detail Rectified Rectified Rectified
Finish Matte Matte Matte
Faces 30 10 24
Thickness (in.)* 3/8 3/8 3/8
Lbs/PC 7.70 30.80 27.50
Grout Joint Recommendation (in.) 1/8 1/8

 1/8

* Tile thickness could vary based on size. Larger format tiles will have a higher thickness.

**TIP ( Testing is in progress, and results will be available soon.)

Testing

Method Results
Abrasion Resistance C1027* III
Breaking Strength C648 >500
Chemical Resistance C650 Resistant
Water Absorption C373 Resistant

DCOF AcuTest WET

>0.60
Scratch Hardness MOHS 7
Shade Variation V2
VOC None

Download and View SDS

Download and View HPD

Download and View LEED

Download 3 Part CSI

Download and View Care And Maintenance

* The beauty of high gloss or polished products may be susceptible to scratching that is more visible on the surface of the tile.

**TIP ( Testing is in progress, and results will be available soon.)

12” x 23”  (actual size 11.69" x 23.46")

23” x 47”  (actual size 23.46" x 47.01")

31" x 31" (actual size 31.39" x 31.39")


USAGE TYPES: YES/NO
COMMERCIAL FLOOR* YES
RESIDENTIAL AND COMMERCIAL WALL YES
SHOWER WALL YES
SHOWER FLOOR YES
STEAM SHOWER YES
KITCHEN COUNTER YES
STOVE AREA YES
FIREPLACE FACADE YES
COVERED EXTERIOR WALL FREEZING CLIMATES YES
COVERED EXTERIOR WALL NON-FREEZING CLIMATES YES
UNCOVERED EXTERIOR WALL FREEZING CLIMATES YES
UNCOVERED EXTERIOR WALL NON-FREEZING CLIMATES YES
COVERED EXTERIOR FLOOR FREEZING CLIMATES YES
COVERED EXTERIOR FLOOR NON-FREEZING CLIMATES YES
UNCOVERED EXTERIOR FLOOR FREEZING CLIMATES YES
UNCOVERED EXTERIOR FLOOR NON-FREEZING CLIMATES YES
POOL DECK YES
POOL WATERLINE YES
INSIDE POOL YES
SPA / HOT TUB YES
UV/ SUN EXPOSURE SENSITIVE NO

* Emser recommends a .50 or greater DCOF for Commercial Dining Floors.

**TIP ( Testing is in progress, and results will be available soon.)

The usage chart is provided as a general guide only. Actual job site conditions may change a product’s suitability for a specific application. If special conditions apply, please contact an Emser representative for clarification of use prior to purchasing.

Loading...

SKU:

A40NETWWH1223


Name:

Color
Network White
Network Silver
Network Gray
Network Taupe
Color Name
White
Light Gray
Gray
Taupe
View in Visualizer
