ILLUMINA™
GLASS & STONE MOSAIC BLEND
Description
Illumina™ series plays with texture, merging the natural beauty of stone and glass in a modern mosaic setting.
5 Colors | 1 Size
Technical Specifications
| Nominal Size (in.) | 12 x 12 Mosaic |
| Edge Detail | Eased |
| Finish | Glossy |
| Faces | Random |
| Thickness (in.)* | 5/16 |
| Lbs/PC | 3.74 |
| Grout Joint Recommendation (in.) | 1/16 |
* Tile thickness could vary based on size. Larger format tiles will have a higher thickness.
Testing
| Method | Results |
| Abrasion Resistance C1027 | 0 |
| Breaking Strength C648 | ≥ 250 |
| Chemical Resistance C650 | Non-Resistant |
| Water Absorption C373 | ≤ 0.50 |
| DCOF AcuTest WET | - |
| Freeze-Thaw Cycling C1026 | Non-Resistant |
| Scratch Hardness MOHS | 5 |
| Shade Variation |
V1 Low |
| Pre-Consumer Recycled Content | 0% |
| Post-Consumer Recycled Content | 0% |
| VOC | None |
Download and View Care and Maintenance
Sizes and Trim
12”x12” Mesh 11.73”x11.73
Usage
| USAGE TYPES: | YES/NO |
| COMMERCIAL FLOOR* | No |
| RESIDENTIAL FLOOR | No |
| RESIDENTIAL AND COMMERCIAL WALL | Yes |
| SHOWER WALL | Yes |
| SHOWER FLOOR | No |
| STEAM SHOWER | No |
| KITCHEN COUNTER | No |
| STOVE AREA | Yes |
| FIREPLACE FACADE | Yes |
| COVERED EXTERIOR WALL FREEZING CLIMATES | No |
| COVERED EXTERIOR WALL NON-FREEZING CLIMATES | No |
| UNCOVERED EXTERIOR WALL FREEZING CLIMATES | No |
| UNCOVERED EXTERIOR WALL NON-FREEZING CLIMATES | No |
| COVERED EXTERIOR FLOOR FREEZING CLIMATES | No |
| COVERED EXTERIOR FLOOR NON-FREEZING CLIMATES | No |
| UNCOVERED EXTERIOR FLOOR FREEZING CLIMATES | No |
| UNCOVERED EXTERIOR FLOOR NON-FREEZING CLIMATES | No |
| POOL DECK | No |
| POOL WATERLINE | No |
| INSIDE POOL | No |
| SPA / HOT TUB | No |
| UV/ SUN EXPOSURE SENSITIVE | Yes |
* Emser recommends a .50 or greater DCOF for Commercial Dining Floors.
The usage chart is provided as a general guide only. Actual job site conditions may change a product’s suitability for a specific application. If special conditions apply, please contact an Emser representative for clarification of use prior to purchasing.
