EMCORE™ 20 MIL VINYL PLANK
LUXURY VINYL TILE
Emcore by Emser Tile™ is a 5MM SPC product with a 20 mil wear layer. This collection of vinyl plank products is appropriate for any interior flooring application. Emcore by Emser Tile™ is a solid-core construction, waterproof material that is stain-, scratch- and dent-resistant. It is offered with 15 different graphic faces and a Uniclic® Locking System that provides the realistic look of wood with easier installation and maintenance.
6 Colors | 1 Size
|Nominal Size (in.)||7" x 48"
|Underlayment||1.5mm IXPE Pad|
|Click System||Uniclic® (Short & Long)|
|Warranty||35 Year Limited Residential Wear Warranty
5 Year Limited Commercial Wear Warranty
The Emcore™ collection by Emser Tile™ contains no phthalates or heavy metal and is 100% virgin vinyl.
|Squareness ASTM F2421||PASS|
|Dimensional Tolerances ISO 24337||PASS|
|Dimensional Stability ASTM F2199||PASS|
|Slip Resistance DIN 51130||R 10|
|Residual Indentation ASTM F1914||PASS (0.001”)|
|Deep Abrasion ASTM D4060||25,000 CYCLES|
|Resistance to Bacteria ASTM G21||0 - PASS|
|Castor Chair Resistance ANSI LF-01||PASS (25,000 CYCLES)|
|Heat Stability ASTM F1514||PASS (<2MM)|
|Resistance to Chemicals ASTM F925||PASS|
|Smoke Density ASTM E662||<450|
|Impact Sound Reductions ASTM E2179||Δ IIC 55 dB|
|Stain Resistance ASTM E423||NOT AFFECTED|
|Heavy Metals ASTM F963-16||FREE - PASS|
|Emissions Testing CDHP/CAL 1350||PASS (0g/L)|
|VOC Requirements ASTM D5116||PASS (0g/L)|
Sizes and Trim
7" x 48"
The usage chart is provided as a general guide only. Actual job site conditions may change a product’s suitability for a specific application. If special conditions apply, please contact an Emser representative for clarification of use prior to purchasing.
