EMCORE™ 12 MIL VINYL PLANK

LUXURY VINYL TILE
Description

Emcore™ is a 5MM SPC product with a 12 mil wear layer. This collection of vinyl plank products is appropriate for any interior flooring application. Emcore™ is a solid-core construction, waterproof material that is stain-, scratch- and dent-resistant. It is offered with 15 different graphic faces and a Uniclic® Locking System that provides the realistic look of wood with easier installation and maintenance.

View UNICLIC Locking System Installation and Maintenance Instructions

Color: Monarch Stuart
SKU Y01MONAST0748
SKU Y01MONAST0748
Sample Price: Sold out
Original price $0.00 - Original price $0.00
Original price
$0.00
$0.00 - $0.00
Current price $0.00

Technical Specifications

Technical Specifications

6 Colors | 1 Size

Technical Specifications

Nominal Size (in.) 7" x 48"
Edge Detail Interlock
Faces 15
Thickness (mm)* 5mm
Wear Layer

12mil

Solid Core

3.2mm

Underlayment 1mm IXPE Pad
Click System Uniclic® (Short & Long)
UV Coating Yes
Water Resistant Yes
Warranty 35 Year Limited Residential Wear Warranty
5 Year Limited Commercial Wear Warranty

The Emcore™ collection by Emser Tile™ contains no phthalates or heavy metal and is 100% virgin vinyl.

Testing

Method Results
Squareness ASTM F2421 PASS
Dimensional Tolerances ISO 24337 PASS
Dimensional Stability ASTM F2199 PASS
Slip Resistance DIN 51130 R 10
Residual Indentation ASTM F1914 PASS (0.001”)
Deep Abrasion ASTM D4060 25,000 CYCLES
Resistance to Bacteria ASTM G21 0 - PASS
Castor Chair Resistance ANSI LF-01 PASS (25,000 CYCLES)
Heat Stability ASTM F1514 PASS (<2MM)
Resistance to Chemicals ASTM F925 PASS
Smoke Density ASTM E662 <450
Impact Sound Reductions ASTM E2179 Δ IIC 55 dB
Stain Resistance ASTM E423 NOT AFFECTED
Heavy Metals ASTM F963-16 FREE - PASS
Emissions Testing CDHP/CAL 1350 PASS (0g/L)
VOC Requirements ASTM D5116 PASS (0g/L)



Sizes and Trim

7" x 48"


TRIM


Usage
USAGE TYPES: YES/NO
COMMERCIAL FLOOR YES
RESIDENTIAL FLOOR YES


The usage chart is provided as a general guide only. Actual job site conditions may change a product’s suitability for a specific application. If special conditions apply, please contact an Emser representative for clarification of use prior to purchasing.
