CATALYST™
RESIN CAST STONE MOSAIC
Description
With an interesting mix of materials, Catalyst™ creates an exclusive collection of surface effects. This line presents an array of options using hexagon shaped mosaics and combinations of textures made of glass, cast stone and natural stone.
4 Colors | 1 Size
Technical Specifications
| Nominal Size (in.) | 13 x 14 |
| Edge Detail | Eased |
| Finish | Satin |
| Faces | Random |
| Thickness (in.)* | 5/16 |
| Lbs/PC | 7.94 |
| Grout Joint Recommendation (in.) | 1/16 |
* Tile thickness could vary based on size. Larger format tiles will have a higher thickness.
Testing
| Method | Results |
| Abrasion Resistance C1027 | II |
| Breaking Strength C648 | >250 lbf |
| Chemical Resistance C650 | Nonresistant |
| Water Absorption C373 |
≤ 0.50 |
| DCOF AcuTest WET | ≥0.42 |
| Freeze-Thaw Cycling C1026 | Nonresistant |
| Scratch Hardness MOHS | 3 |
| Shade Variation | V1 |
| Pre-Consumer Recycled Content | 0% |
| Post-Consumer Recycled Content | 0% |
| VOC | None |
Download and View Care and Maintenance
Sizes and Trim
13”x14” Decorative Mesh Mosaic
Usage
| USAGE TYPES: | YES/NO |
| COMMERCIAL FLOOR* | No |
| RESIDENTIAL FLOOR | Yes |
| RESIDENTIAL AND COMMERCIAL WALL | Yes |
| SHOWER WALL | Yes |
| SHOWER FLOOR | Yes |
| STEAM SHOWER | Yes |
| KITCHEN COUNTER | No |
| STOVE AREA | No |
| FIREPLACE FACADE | Yes |
| COVERED EXTERIOR WALL FREEZING CLIMATES | No |
| COVERED EXTERIOR WALL NON-FREEZING CLIMATES | No |
| UNCOVERED EXTERIOR WALL FREEZING CLIMATES | No |
| UNCOVERED EXTERIOR WALL NON-FREEZING CLIMATES | No |
| COVERED EXTERIOR FLOOR FREEZING CLIMATES | No |
| COVERED EXTERIOR FLOOR NON-FREEZING CLIMATES | No |
| UNCOVERED EXTERIOR FLOOR FREEZING CLIMATES | No |
| UNCOVERED EXTERIOR FLOOR NON-FREEZING CLIMATES | No |
| POOL DECK | No |
| POOL WATERLINE | No |
| INSIDE POOL | No |
| SPA / HOT TUB | No |
| UV/ SUN EXPOSURE SENSITIVE | Yes |
* Emser recommends a .50 or greater DCOF for Commercial Dining Floors.
The usage chart is provided as a general guide only. Actual job site conditions may change a product’s suitability for a specific application. If special conditions apply, please contact an Emser representative for clarification of use prior to purchasing.
