PASSION™
GLAZED PORCELAIN*
Description
The striking colors of Passion™ will inspire breathtaking designs throughout any living space. This unique wall tile transcends traditional subway tiles into something ethereal. Colors ranging from soft White to delicate Rosa to deep Azul, Passion™ brings a truly magical element that will complement any decor.
Technical Specifications
7 Colors | 2 Sizes
Technical Specifications
| Nominal Size (in.) | 3" x 8"; 9" x 9" |
| Edge Detail | Pressed |
| Finish | Glossy |
| Faces | 30 |
| Thickness (mm.)* | 10 |
| Lbs/PC | 0.55 |
| Grout Joint Recommendation (in.) | 1/8" |
* Tile thickness could vary based on size. Larger format tiles will have a higher thickness.
Testing
| Method | 3" x 8" | 9" x 9" |
| Abrasion Resistance C1027 | III | Glossy: III Matte: IV |
| Breaking Strength C648 | >250 | >350 |
| Chemical Resistance C650 | RESISTANT | RESISTANT |
| Water Absorption C373 | <1% | <3.0% |
| DCOF AcuTest WET | <0.42 | <0.42 |
| Freeze-Thaw Cycling C1026 | TIP | TIP |
| Scratch Hardness MOHS | 7 |
Glossy: 6 Matte: 7 |
| Shade Variation | V3 | TIP |
| Pre-Consumer Recycled Content | 0% | TIP |
| Post-Consumer Recycled Content | 0% | TIP |
| VOC | None | TIP |
*Frost Resistant Tile. This product is not classified as true porcelain as the water absorption falls within 0.5% - 3%. However, this product is able to be used almost anywhere porcelain tile is used.
Download and View Care and Maintenance
- Grout joint recommendation: 1/8”
- Tile thickness could vary based on size.
- Larger format tiles will have a higher thickness.
Sizes and Trim
Usage
| USAGE TYPES: | YES/NO |
| COMMERCIAL FLOOR* | NO |
| RESIDENTIAL FLOOR | YES |
| RESIDENTIAL AND COMMERCIAL WALL | YES |
| SHOWER WALL | YES |
| SHOWER FLOOR | NO |
| STEAM SHOWER | YES |
| KITCHEN COUNTER | YES |
| STOVE AREA | YES |
| FIREPLACE FACADE | YES |
| EXTERIOR WALL | TIP |
| EXTERIOR FLOOR | TIP |
| POOL DECK | 9" x 9" Matte Only |
| POOL WATERLINE | YES |
| INSIDE POOL | NO |
| SPA / HOT TUB | NO |
| UV/ SUN STABLE | YES |
* Emser recommends a .50 or greater DCOF for Commercial Dining Floors.
The usage chart is provided as a general guide only. Actual job site conditions may change a product’s suitability for a specific application. If special conditions apply, please contact an Emser representative for clarification of use prior to purchasing.
