HANGAR™
GLAZED BODY MATCH PORCELAIN
Description
Combined with its concrete, linear pattern, Hangar™ delivers a flexible, modern solution offered in large format panels in a trending tile size.
4 Colors | 4 Sizes
Technical Specifications
| Nominal Size (in.) | 63 x 126 | 23 x 47 | 31 x 31 | 12 x 23 |
| Edge Detail | Rectified | Rectified | Rectified | Rectified |
| Finish | Satin | Satin | Satin | Satin |
| Faces | TBD | TBD | TBD | TBD |
| Thickness (in.)* | 5/16 | 5/16 | 5/16 | 3/8 |
| Lbs/PC | 205.03 | 27.78 | 24.69 | 7.78 |
| Grout Joint Recommendation (in.) | TBD | 3/16 | 1/8 | 1/8 |
* Tile thickness could vary based on size. Larger format tiles will have a higher thickness.
Testing
| Method | Results |
| Abrasion Resistance C1027 | V |
| Breaking Strength C648 | ≥300 |
| Chemical Resistance C650 | Resistant |
| Water Absorption C373 |
≤0.50 |
|
DCOF AcuTest WET |
≥0.45 |
| Freeze-Thaw Cycling C1026 | Resistant |
| Scratch Hardness MOHS | 7 |
| Shade Variation |
V2 |
| Pre-Consumer Recycled Content | 0% |
| Post-Consumer Recycled Content | 0% |
| VOC | None |
Download and View Care and Maintenance
Sizes and Trim
63" x 126"
31” x 31”
23” x 47”
12” x 23”
Usage
| USAGE TYPES: | YES/NO |
| COMMERCIAL FLOOR* | Yes |
| RESIDENTIAL FLOOR | Yes |
| RESIDENTIAL AND COMMERCIAL WALL | Yes |
| SHOWER WALL | Yes |
| SHOWER FLOOR | Yes |
| STEAM SHOWER | Yes |
| KITCHEN COUNTER | Yes |
| STOVE AREA | Yes |
| FIREPLACE FACADE | Yes |
| COVERED EXTERIOR WALL FREEZING CLIMATES | Yes |
| COVERED EXTERIOR WALL NON-FREEZING CLIMATES | Yes |
| UNCOVERED EXTERIOR WALL FREEZING CLIMATES | Yes |
| UNCOVERED EXTERIOR WALL NON-FREEZING CLIMATES | Yes |
| COVERED EXTERIOR FLOOR FREEZING CLIMATES | No |
| COVERED EXTERIOR FLOOR NON-FREEZING CLIMATES | No |
| UNCOVERED EXTERIOR FLOOR FREEZING CLIMATES | No |
| UNCOVERED EXTERIOR FLOOR NON-FREEZING CLIMATES | No |
| POOL DECK | Yes |
| POOL WATERLINE | Yes |
| INSIDE POOL | Yes |
| SPA / HOT TUB | Yes |
| UV/ SUN EXPOSURE SENSITIVE | No |
* Emser recommends a .50 or greater DCOF for Commercial Dining Floors.
The usage chart is provided as a general guide only. Actual job site conditions may change a product’s suitability for a specific application. If special conditions apply, please contact an Emser representative for clarification of use prior to purchasing.
