EXPANSE™

GLAZED & THROUGHBODY PORCELAIN

The flexibility of Expanse™ allows the various product collections to be complete projects ranging from simple small spaces to large commercial surfaces.

7 Stocking Colors | 6 Sizes* | 1/4”  &  5/16" Thickness

*Not all sizes are stocked. Some sizes are Lead Time Required

17 Lead Time Required Colors | 5 Sizes | 1/4” Thickness

Technical Specifications
Test Method Results
Abrasion Resistance C1243 1
Breaking Strength C648

≥250lbf

Chemical Resistance C650 Resistant
Water Absorption C373

≤.50

DCOF AcuTest WET

M/L ≥.60

P <.42

Freeze-Thaw Cycling C1026 Resistant
Scratch Hardness MOHS 6
Shade Variation

V2

Green Friendly: VOC None | Recycled Content Varies by Color

Download and View SDS

Download and View HPD

Download and View LEED

Download 3 Part CSI

Download and View Care and Maintenance

  • Grout joint recommendation: 1/8”
  • Tile thickness could vary based on size.
  • Larger format tiles will have a higher thickness.

Stocked Sizes not available for all Colors.

63" x 126"

59" x 118"

39" x 118"



"Lead Time Required" sizes not available for all colors.

39" x 39"

31" x 31"

39" x 59"

29" x 59"

23" x 47"

15" x 29"

USAGE TYPES: YES/NO
COMMERCIAL FLOOR Yes
COMMERCIAL DINING FLOOR

Honed & Lapatto - Yes

Polished - No

RESIDENTIAL FLOOR Yes
RESIDENTIAL AND COMMERCIAL WALL Yes
SHOWER WALL Yes
SHOWER FLOOR Yes
STEAM SHOWER Yes
KITCHEN COUNTER Yes
STOVE AREA Yes
FIREPLACE FACADE Yes
COVERED EXTERIOR WALL FREEZING CLIMATES Yes
COVERED EXTERIOR WALL NON-FREEZING CLIMATES Yes
UNCOVERED EXTERIOR WALL FREEZING CLIMATES Yes
UNCOVERED EXTERIOR WALL NON-FREEZING CLIMATES Yes
COVERED EXTERIOR FLOOR FREEZING CLIMATES

Honed & Lapatto - Yes

Polished - No

COVERED EXTERIOR FLOOR NON-FREEZING CLIMATES

Honed & Lapatto - Yes

Polished - No

UNCOVERED EXTERIOR FLOOR FREEZING CLIMATES

Honed & Lapatto - Yes

Polished - No

UNCOVERED EXTERIOR FLOOR NON-FREEZING CLIMATES

Honed & Lapatto - Yes

Polished - No

POOL DECK

Honed & Lapatto - Yes

Polished - No

POOL WATERLINE Yes
INSIDE POOL Yes
SPA / HOT TUB Yes
UV/ SUN EXPOSURE SENSITIVE No

The usage chart is provided as a general guide only. Actual job site conditions may change a product’s suitability for a specific application. If special conditions apply, please contact an Emser representative for clarification of use prior to purchasing.

Loading...

SKU:

V54EXPACAM59118P


Name:

Color
Calacata Mix
Calacata A
Calacata B
Demi White
Vagli A
Vagli B
Trosa Mix
Savoia Grey
Isla Natura
Onice Bianco
Onice Oro
Verso Brown
Verso Black
Cement White
Cement Grey
Cement Rust
Cement Nero
Basalt Grey
Basalt Nero
Puro Bianco
Puro Nero
Misto Luna
Misto Nero
Hangar Ash
Hangar Sand
Hangar Smoke
Hangar Coal
Color Name
White
Ivory
Blue
Taupe
Beige
Gold
Black
Gray
Copper
View in Visualizer
