CODE™

GLAZED PORCELAIN / GLAZED CERAMIC WALL TILE
Description

The integration of light and shadow effects create dimensional vertical surfaces using simple shapes that shifts and transform. Trapezoid-shaped floor tiles allow for unique and interesting compositions. Code's™ minimal and neutral forms offer endless design opportunities for every surface.

Color: Code White
SKU W10CODSWH0607HX
Available Sizes: 6" x 7" Hexagon Smooth
SKU W10CODSWH0607HX
SKU W10CODSWH0607HX
Sample Price:
Original price $3.00 - Original price $3.00
Original price
$3.00
$3.00 - $3.00
Current price $3.00

4 Colors | 4 Patterns | 3 Shapes

Technical Specifications

Shape  High & 3D (Wall Only)  Smooth & Line (Wall Only) Trapezoid (Floor & Wall)
Nominal Size (in.)

Hex High/3D: 6 x 7

Wedge High/3D:

5 x 6

Hex Smooth/Line:

6 x 7

Wedge Smooth:

5 x 6

4 x 9
Edge Detail Pressed Pressed Pressed
Finish Satin/Gloss Satin Satin
Faces 1 1 1
Thickness (in.)* 7/8 5/16 5/16
Lbs/PC

Hex High/3D: .88

Wedge: .66

Hex Smooth: .44

Wedge Smooth: .44

.88
Grout Joint Recommendation (in.) 1/8 1/8 3/16

* Tile thickness could vary based on size. Larger format tiles will have a higher thickness.

Technical Specifications
ASTM Test Results
Abrasion Resistance C1027

Trapezoid: III

High/3D & Smooth: 0

Breaking Strength C648 ≥250 lbf
Chemical Resistance C650 Resistant
Water Absorption C373 ≤0.50%
DCOF AcuTest WET ≥0.65
Freeze-Thaw Cycling C1026 Resistant
Scratch Hardness MOHS 6
Shade Variation V2
Pre-Consumer Recycled Content 0%
Post-Consumer Recycled Content 0%
VOC None

Download and View SDS

Download and View HPD

Download and View LEED

Download 3 Part CSI

Download and View Care and Maintenance

Sizes and Trim

6” x 7” Hexagon



5" x 6" Wedge

4" x 9" Trapezoid

Usage

USAGE TYPES: YES/NO
COMMERCIAL FLOOR* Trapezoid Only
RESIDENTIAL FLOOR Trapezoid Only
RESIDENTIAL AND COMMERCIAL WALL Yes
SHOWER WALL Yes
SHOWER FLOOR

Trapezoid Only
STEAM SHOWER

Yes
KITCHEN COUNTER Trapezoid Only
STOVE AREA

Yes
FIREPLACE FACADE

Yes
COVERED EXTERIOR WALL FREEZING CLIMATES


Trapezoid Only
COVERED EXTERIOR WALL NON-FREEZING CLIMATES

Yes
UNCOVERED EXTERIOR WALL FREEZING CLIMATES Trapezoid Only
UNCOVERED EXTERIOR WALL NON-FREEZING CLIMATES


Trapezoid Only
COVERED EXTERIOR FLOOR FREEZING CLIMATES Trapezoid Only
COVERED EXTERIOR FLOOR NON-FREEZING CLIMATES Trapezoid Only
UNCOVERED EXTERIOR FLOOR FREEZING CLIMATES Trapezoid Only
UNCOVERED EXTERIOR FLOOR NON-FREEZING CLIMATES Trapezoid Only
POOL DECK Trapezoid Only
POOL WATERLINE Trapezoid Only
INSIDE POOL Trapezoid Only
SPA / HOT TUB Trapezoid Only
UV/ SUN EXPOSURE SENSITIVE No

* Emser recommends a .50 or greater DCOF for Commercial Dining Floors.

The usage chart is provided as a general guide only. Actual job site conditions may change a product’s suitability for a specific application. If special conditions apply, please contact an Emser representative for clarification of use prior to purchasing.
